GF-EXT-DP1-HBT3

DisplayPort 1.2a KVM Extender

DisplayPort GF-EXT-DP1-HBT3 Extender provides seamless extension of uncompressed DisplayPort signals.

Available for Pre-Order

Description

GF-EXT-DP1-HBT3 – DisplayPort 1.2a KVM Extender over HDBaseT 3

DisplayPort HDBaseT 3.0 KVM Extender with 4K60 and Control Signals

The Gefen GF-EXT-DP1-HBT3 is a professional-grade DisplayPort 1.2a HDBaseT 3.0 KVM Extender designed to transmit uncompressed 4K60 DisplayPort 1.2a video, USB control, audio, and RS-232 signals up to 100 meters over a single CAT6A cable. Built for integrators and system designers, this solution is ideal for legacy DisplayPort environments that demand high-performance signal extension with streamlined cabling.

4K60 Video and Legacy DisplayPort Compatibility

As a robust DisplayPort 1.2a HDBaseT 3.0 KVM Extender, the GF-EXT-DP1-HBT3 supports 4K60 (4:4:4) resolution with HDR passthrough. It delivers pixel-perfect performance without latency or compression. This makes it ideal for applications such as command centers, education, healthcare, and commercial displays that still utilize DisplayPort 1.2a infrastructure.

USB KVM and Bidirectional RS-232 Extension

Incorporating full USB 2.0 functionality, this KVM extender over HDBaseT supports remote keyboard, mouse, and peripheral operation. It includes two USB-A and one USB-C port on the Receiver for flexible endpoint connectivity. Bidirectional RS-232 ensures remote device control, while HDCP 2.3 compliance and EDID management provide seamless communication between source and display.

USB, Audio, and Control Integration for Pro-Grade Flexibility

Beyond video, the DisplayPort HDBaseT 3.0 KVM Extender supports full USB 2.0 pass-through, enabling seamless KVM functionality for remote desktop control. The system features a USB-C host port on the transmitter and multiple USB-A and USB-C ports on the receiver, supporting HID devices and bulk transfers. Bidirectional RS-232 and Ethernet ensure full compatibility with control systems and IP-based network environments.

Flexible Audio Support and Gigabit Ethernet

The system supports multichannel embedded audio and stereo analog audio de-embedding for integration into professional AV environments. Gigabit Ethernet passthrough enables connected devices or remote management systems. Whether used in a networked AV system or standalone extension, this DisplayPort HDBaseT 3.0 KVM Extender ensures reliability and flexibility.

Installation Efficiency with Power over HDBaseT

PoH simplifies power requirements by allowing either the Transmitter or Receiver to power the system. Compact metal enclosures with locking power supplies and rack-mount kits make it easy to deploy in commercial installations. This extender is ideal for legacy DisplayPort environments needing long-range digital signal extension.

Features

  • Extends DisplayPort 1.2a video, USB 2.0, RS-232, analog audio, and Ethernet up to 100 meters (328 feet) over a single CAT6A/7 cable.
  • Supports resolutions up to 4K@60Hz 4:4:4 with uncompressed video transmission.
  • Fully compliant with DisplayPort 1.2a and HDCP 2.2 standards.
  • Supports HDR10, HDR10+, Dolby Vision, and HLG passthrough.
  • USB 2.0 pass-through:
    • (1) USB-C Host Port (TX)
    • (2) USB-A Device Ports + (2) USB-C Device Ports (RX)
  • Bi-directional stereo audio pass-through and balanced stereo audio de-embedding at the Receiver.
  • Audio formats supported: PCM 2.0/5.1/7.1, Dolby Atmos®, Dolby TrueHD, DTS-HD Master Audio™, DTS:X™.
  • EDID management: Copy EDID from sink or select Gefen Internal EDID (2ch Audio).
  • Selectable HDCP passthrough/block mode via DIP switches.
  • RS-232 pass-through for system control or firmware updates.
  • Gigabit Ethernet pass-through (100M/1G auto-negotiation).
  • Two-way PoH (Power over HDBaseT) reduces cabling complexity.
  • HPD always active to ensure source stability.
  • Eco-friendly packaging, RoHS, REACH, and Prop 65 compliant.

Specifications

  • Video Performance:

    • DisplayPort 1.2a compliant
    • Up to 4K@60Hz 4:4:4
    • HDCP 2.2 compliant
    • HDR10, HDR10+, Dolby Vision, HLG

    Audio Performance:

    • DP Audio and Analog Audio Pass-through:
      • LPCM 2/5.1/7.1, Dolby TrueHD, Dolby Atmos, DTS-HD Master Audio, DTS:X
    • Stereo Analog Audio In/Out (3.5mm jack, TRS)
    • Balanced Audio De-embed (5-pin 3.5mm Phoenix, RX only)
    • Output Level (0dB FS): 1.8–2Vrms
    • SNR > 80dB (20Hz–20kHz)
    • THD < 0.05% @1kHz

    USB 2.0 Performance:

    • Host Interface (TX): USB-C
    • Device Ports (RX): (2) USB-A + (2) USB-C
    • Max bandwidth: 350Mbps
    • Supports HID, isochronous, and bulk transfers

    Connections (Transmitter – TX):

    • (1) DisplayPort Input (Type A, 20-pin)
    • (1) HDBaseT Output (RJ-45, PoH enabled)
    • (1) 3.5mm Audio In (Stereo)
    • (1) 3.5mm Audio Out (Stereo)
    • (1) RS-232 (3-pin Phoenix, 3.5mm pitch)
    • (1) Ethernet Port (RJ-45)
    • (1) USB-C Host Port
    • (1) 4-pin DIP Switch (EDID, HDCP, Firmware update control)
    • (1) DC 12V Locking Power Connector
    • LEDs: Power (Blue), Link (Green), Video (Green)

    Connections (Receiver – RX):

    • (1) DisplayPort Output (Type A, 20-pin)
    • (1) HDBaseT Input (RJ-45, PoH enabled)
    • (1) 3.5mm Audio In (Stereo)
    • (1) 3.5mm Audio Out (Stereo)
    • (1) Balanced Audio Output (5-pin Phoenix)
    • (1) RS-232 (3-pin Phoenix)
    • (1) Ethernet Port (RJ-45)
    • (2) USB-A Device Ports
    • (2) USB-C Device Ports
    • (1) 4-pin DIP Switch
    • (1) DC 12V Locking Power Connector
    • LEDs: Power (Blue), Link (Green), Video (Green)

    Mechanical:

    • Metal Enclosure
    • Dimensions: 215mm (W) × 120mm (D) × 25mm (H)

    Environmental:

    • Operating Temp: 0°C to 50°C (32°F to 122°F)
    • Storage Temp: -20°C to 60°C (-4°F to 140°F)
    • Humidity: 20–90% RH (non-condensing)
    • ESD Protection: ±8kV (Air), ±4kV (Contact)
    • Vibration: ISTA-1A Certified

    Power Requirements:

    • DC 12V/3A Power Supply (included, multi-region plugs)
    • Two-way PoH supported

    Box Contents:

    • DisplayPort KVM Extender Set (TX + RX)
    • (1) 12V/3A Power Supply (US/EU/UK/AU Cords)
    • (2) 3.5mm 3-pin Phoenix Connectors
    • (1) 1.8m USB-A to USB-C Cable
    • (4) Mounting Ears with Screws
    • (1) Gefen Quick Start Guide

    Certifications:

    • EMC: FCC Part 15 Class B, ICES-003, CE, UKCA, AS/NZS CISPR32
    • Environmental: RoHS, REACH, Conflict Minerals, Prop 65

Warranty

3 year product warranty

Please see the Gefen warranty page for more details
