What video resolutions and frame rates does the Gefen GF-EXT-HDK-HBT2 support?

The extender supports uncompressed 8K@60Hz (4:2:0) and 4K@120Hz video, ensuring ultra-high-definition visuals without compression artifacts.

Can I use USB peripherals like keyboards and touchscreens with this extender?

Yes, it supports USB 2.0 KVM extension allowing seamless connection and control of HID devices including keyboards, mice, and touchscreens.

How far can the video and USB signals be extended?

This device extends HDMI video, audio, and USB signals up to 100 meters (330 feet) over a single CAT cable using HDBaseT 2.0 technology.

Does the extender support HDR and audio features?

Yes, it supports HDR10 for enhanced video dynamic range and Dolby Audio, along with analog audio de-embedding and eARC for flexible audio setups.

Is power supply required separately or included?

The extender supports bi-directional Power over HDBaseT (PoH+), enabling power delivery via the CAT cable, simplifying installation. It also accepts 12V DC power supply.

How does the extender ensure consistent signal quality?

It incorporates EDID management and HPD signal stability features to maintain reliable connectivity and prevent signal loss or display issues.

Can the firmware be updated to support future standards?

Yes, firmware is field-upgradable via a USB Type-C service port, helping to extend product longevity and maintain compatibility as AV standards evolve when updates are provided.

The Wait is Almost Over. Preorder Today!

HDMI KVM HDBaseT 3.0 (GF-EXT-HDe-HBT3)

Name: HDMI KVM HDBaseT 3.0 (GF-EXT-HDe-HBT3)
Brand: Gefen
SKU: GF-EXT-HDe-HBT3
Price: 1323.94 USD
Availability: InStock

GF-EXT-HDe-HBT3

When picture and sound quality truly matter, the Gefen GF-EXT-HDe-HBT3 delivers uncompromised clarity and control across long runs. Powered by HDBaseT 3.0 technology, it extends 4K @ 60 Hz 4:4:4 video, eARC/ARC audio, and Ethernet up to 100 meters (330 feet) over a single CAT6a cable. With full HDR10+, Dolby Vision, and HLG support, plus flexible analog and optical audio outputs, it maintains studio-quality color and sound from source to display. EDID management, signal diagnostics, and a built-in pattern generator streamline
setup for integrators. Whether in a home theater, boardroom, or broadcast suite, the GF-EXT-HDe-HBT3 is built to perform with precision; preserving every detail, frame, and frequency along the way.

❗Comes with both Sender and Receiver

$1,323.94

HDMI KVM HDBaseT 3.0 (GF - EXT - HDe - HBT3) - GF-EXT-HDe-HBT3 - Gefen

Key Features

Extends 4K@60Hz 4:4:4 video up to 330 feet over single CAT6a cable with HDR10+, Dolby Vision, and HLG support for uncompromised picture quality

eARC/ARC audio return with adaptive intelligence automatically detects PCM and bitstream sources, plus analog and optical de-embedding outputs

Integrated EDID management and pattern generator streamline installation testing and prevent audio dropouts without external equipment

Bi-directional Power over Cable (PoC) eliminates dual power supplies while supporting RS-232 and IR control pass-through

Commercial-grade metal housing with surface-mount brackets, energy-efficient <15W operation, and firmware-upgradeable via USB-C

How It Works

The Gefen GF-EXT-HDe-HBT3 uses HDBaseT 3.0 technology to transmit uncompressed 4K@60Hz video, eARC/ARC audio, and control signals over a single CAT6a cable up to 330 feet. Connect your HDMI source to the sender unit (TX), which encodes the 18Gbps signal and transmits it to the receiver unit (RX) at your display location. The system uses bi-directional Power over Cable (PoC), so you only need to power one unit—it automatically supplies power to the other through the network cable. Smart EDID management maintains handshake integrity between devices while adaptive audio intelligence automatically detects and optimizes PCM or bitstream sources, with options to de-embed audio via analog or optical outputs at either end. LED indicators provide real-time monitoring of power, link, video, and eARC status throughout operation.
