DVI to VGA Converter & Adapter (DVI-D to VGA) (EXT-DVI-2-VGAN)

Name: DVI to VGA Converter & Adapter (DVI-D to VGA) (EXT-DVI-2-VGAN)
Brand: Gefen
SKU: EXT-DVI-2-VGAN
Price: 561.75 USD
Availability: OutOfStock

EXT-DVI-2-VGAN

The Gefen DVI to VGA Converter is a compact and effective solution that converts a DVI-D signal to VGA Analog PC/RGB, seamlessly connecting modern digital sources to any projector, monitor, or TV that uses a VGA input. This DVI to VGA adapter supports VESA resolutions up to 1920x1200, ensuring a high-quality picture. For rapid and reliable integration of your equipment, the converter features advanced EDID management, which helps ensure compatibility between the source and the display

$561.75

DVI to VGA Converter & Adapter (DVI - D to VGA) (EXT - DVI - 2 - VGAN) - EXT - DVI - 2 - VGAN - Gefen

Key Features

Digital to Analog Conversion: Enables a digital DVI source to be displayed on analog VGA monitors or projectors.

High-Resolution Video: Supports VESA resolutions up to 1920x1200 at 60 Hz, delivering clear and detailed video.

Advanced EDID Management: Features a built-in EDID switch to choose between the display's EDID or the unit's internal EDID for rapid integration of the source and display.

How It Works

Using the Gefen DVI to VGA Converter is simple. Connect your DVI source to the DVI In connector on the unit using a DVI cable. Then, connect your VGA monitor or projector to the VGA Out port. Finally, plug the included 5V DC power supply into the converter and an available electrical outlet to power the unit. Once powered on, the converter will adapt the signal from your DVI-D source for viewing on your VGA display.

Additional Information

Specifications

Maximum Pixel Clock: 165MHz (DVI)

Video Bandwidth: 165 MHz

Analog Video Bandwidth: 350MHz (VGA)

Input Video Signal: 1.2 Volts p-p

Input DDC Signal: 5 Volts p-p (TTL)

Video Input Connector: (1) DVI-I 29-pin, female (digital only)

Video Output Connector: (1) VGA HD-15, female

Power Supply: 5V DC

Power Consumption: 2.5 Watts (max.) / 5W (max.)

Operating Temperature: 0 ~ 40°C

Dimensions (from Manual): 3" W x 3.75" H x 1" D

Dimensions (from Datasheet): 3 W x 3.8 D x 1 H

Shipping Weight: 2 lbs.

UPC: 845344042268

System Requirements

The VGA monitor must be able to support the DVI input resolution, as this product does not have scaling capabilities.
This product does not support HDCP content.

What's in the Box

(1) Gefen DVI to VGA Converter
(1) 6 ft DVI cable (M-M)
(1) 5V DC Power Supply
(1) Quick-Start Guide

Warranty

2 Year Product Warranty

Please see the Gefen Warranty Page for more details.

Resources

Gefen EXT-DVI-2-VGAN Datasheet
Gefen EXT-DVI-2-VGAN Manual
Gefen EXT-DVI-2-VGAN Declaration of Conformity
