GTV-DIGAUD-2-AAUD

Digital Audio to Analog Adapter

Converts digital audio to L/R analog audio

Description

The Digital To Analog Audio converter box takes your coaxial/optical (S/PDIF or TOSLink) digital audio source and converts it to standard analog left/right audio, available for connection to an external device such as an amplifier or recording deck via standard RCA-style jacks. Now you can bridge your legacy sound system with digital sources such as DVD and CD players that don’t have RCA-style analog outputs.

Features

  • Converts S/PDIF or TOSLink digital audio signals to analog L/R audio
  • Digital interpolation filter and digital to analog converter (DAC)
  • Accepts uncompressed digital audio as input
  • Samples at 32, 44.1, 48 and 96 KHz
  • 2-channel LPCM (Linear Pulse Code Modulation)
  • 24-bit S/PDIF incoming bitstream on left and right channels
  • Compact and easy to install

Specifications

Coaxial and Optical digital input ports

Right and Left RCA Stereo analog output ports

Distortion: : <0.001% @ 1kHz at 2V RMS

SNR: > 90dB (20Hz – 20kHz A Weighting)

Chassis: White plastic chassis

Operating Temperature: 0-70 deg. C

Power supply: : 5v DC / 5W (US/EU standards, CE/FCC/UL certified)

Dimensions: : 1.8" W x 1.8" H x 0.9" D

Shipping Weight: : 1 lb.

Other Specifications

Shipping Info
  • Length7.48 (Inches)
  • Width5.31 (Inches)
  • Height2.75 (Inches)
  • Weight0.8 (Lbs)
  • UPC845344080567
Other Specifications
  • Coaxial and Optical digital input ports
  • Right and Left RCA Stereo analog output ports
  • Distortion: <0.001% @ 1kHz at 2V RMS
  • SNR: > 90dB (20Hz – 20kHz A Weighting)
  • Chassis: White plastic chassis
  • Operating Temperature: 0-70 deg. C
  • Power supply: 5v DC / 5W (US/EU standards, CE/FCC/UL certified)
  • Dimensions: 1.8" W x 1.8" H x 0.9" D
  • Shipping Weight: 1 lb.
In The Box
  • GefenTV Digital To Analog Audio Adapter (GTV-DIGAUD-2-AAUD)(1)
  • 3 ft. Optical Cable (CAB-TLINK-3MM-O)(1)
  • 5V DC Power Supply (EXT-PS51AIP-O)(1)
  • Quick-Start Guide (QSG-GTV-DIGAUD-2-AAUD)(1)

Warranty

2 year product warranty


Please see the Gefen warranty page for more details
